10-58 SERVICING INFORMATION SUSPENSION Unit: mm (in) ITEM STANDARD LIMIT Front fork stroke 120 — (4.92) Front fork spring free length 230.0 225 (9.06) (8.86) Front fork oil level (without spring, 101 — outer tube fully compressed) (3.98) Front fork oil type SUZUKI FORK OIL L01 or an equivalent fork oil — Front fork oil capacity (each leg) 510 ml — (17.2/17.9 US/Imp oz) Front fork spring adjuster 4 th groove from top — Front fork damping force adjuster Rebound 11 clicks out from stiffest position — (For E-02, 19) Compression 16 clicks out from stiffest position — Front fork damping force adjuster Rebound 9 clicks out from stiffest position — (For E-03, 24, 28, 33) Compression 14 clicks out from stiffest position — Rear shock absorber spring pre-set 177.6 — length (6.99) Rear shock absorber damping Rebound 12 clicks out from stiffest position — force adjuster Compression 14 clicks out from stiffest position — Rear wheel travel 130 — (5.1) E Swingarm pivot shaft runout — L 0.3 P (0.01) FUEL + OIL ITEM SPECIFICATION NOTE M Fuel type Use only unleaded gasoline of at least 90 pump A octane (R/2 + M/2). Gasoline containing MTBE (Methyl Tertiary Butyl S E-03, 28, 33 Ether), less than 10% ethanol, or less than 5% methanol with appropriate cosolvents and corro- sion inhibitor is permissible. Gasoline used should be graded 95 octane or Others higher. An unleaded gasoline is recommended. Fuel tank capacity 17.5 L E-33 Including (4.6/3.8 US/lmp gal) reserve 18 L Others (4.8/4.0 US/lmp gal) Fuel level Approx. 4.5 L indicator light (1.2/1.0 US/lmp gal) lighting Engine oil type SAE 10 W-40, API SF/SG or SH/SJ with JASO MA Engine oil capacity Change 3.0 L (3.2/2.6 US/lmp qt) Filter change 3.3 L (3.5/2.9 US/lmp qt) Overhaul 3.6 L (3.8/3.2 US/lmp qt)
