CHASSIS 8-47 • Tighten the sprocket mounting nuts to the specified torque. Rear sprocket nut: 93 N·m (9.3 kgf-m, 67.5 lb-ft) NOTE: Stamped mark A on the sprocket should face outside. • Install the collar 2. BRAKE DISC • Apply THREAD LOCK to the disc bolts and tighten them to the specified torque. NOTE: Make sure that the brake disc is clean and free of any greasy matter. 99000-32130: THREAD LOCK SUPER “1360” Brake disc bolt: 35 N·m (3.5 kgf-m, 25.5 lb-ft) • Install the collar 1. E REAR AXLE • Remount the rear wheel and rear axle shaft, and install the washer 1 (Except for E-03, 28, 33) and rear axle nut 2. L P • Adjust the chain slack after rear wheel installation. (2-21) M A S
