ENGINE 3-27 ENGINE COMPONENTS INSPECTION AND SERVICE  Identify the position of each removed part. Organize the parts in their respective groups (i.e., intake, exhaust, No.1 or No.2) so that they can be installed in their original locations. CYLINDER HEAD COVER • Clean and check the gasket grooves A and PAIR reed valve gasket mating surfaces B of cylinder head cover. • If it is damaged, replace the cylinder head cover with a new one. CMP SENSOR E REMOVAL L • Remove the CMP sensor 1 from the cylinder head cover. INSPECTION P • Inspect the CMP sensor. (4-33) M A S INSTALLATION • Install the oil seal 2 and CMP sensor 3. NOTE: When installing, clean the CMP sensor’s face. CMP sensor mounting bolt: 8 N·m (0.8 kgf-m, 6.0 lb-ft) PAIR REED VALVE REMOVAL • Remove the PAIR reed valve covers 1.
