5-4 FUEL SYSTEM AND THROTTLE BODY FUEL TANK INSTALLATION • Installation is in the reverse order of removal. FUEL PRESSURE INSPECTION • Lift and support the fuel tank. (5-3) • Place a rag under the fuel feed hose and remove the fuel feed hose 1. • Install the special tools between the fuel tank and fuel delivery pipe. 09940-40211: Fuel pressure gauge adaptor 09940-40220: Fuel pressure gauge hose attachment 09915-77331: Oil pressure gauge 09915-74521: Oil pressure gauge hose E Turn the ignition switch ON and check the fuel pressure. 2 L Fuel pressure: Approx. 300 kPa (3.0 kgf/cm , 43 psi) If the fuel pressure is lower than the specification, inspect the following items: P * Fuel hose leakage M * Clogged fuel filter * Pressure regulator A * Fuel pump S If the fuel pressure is higher than the specification, inspect the following items: * Fuel pump check valve * Pressure regulator  * Before removing the special tools, turn the ignition switch to OFF position and release the fuel pressure slowly. * Gasoline is highly flammable and explosive. Keep heat, sparks and flame away. A To fuel tank B To fuel delivery pipe
