CHASSIS 8-33 REASSEMBLY Reassemble the steering stem in the reverse order of disassem- bly. Pay attention to the following points: OUTER RACE • Press in the upper and lower bearing outer races with the special tools. 09941-34513: Steering outer race installer set 09913-70210: Bearing installer set (55) INNER RACE • Press in the lower bearing inner race with the special tool. 09925-18011: Steering bearing installer INSTALLATION E Install the steering stem in the reverse order of removal. Pay attention to the following points: L BEARING P • Apply SUZUKI SUPER GREASE “A” to the bearings and bearing races. M A 99000-25030: SUZUKI SUPER GREASE “A” (USA) 99000-25010: SUZUKI SUPER GREASE “A” (Others) S • Install the lower bearing to the steering stem lower bracket. • Install the upper bearing and bearing inner race. STEM NUT • Install the dust seal and dust seal cover. • Tighten the steering stem nut to the specified torque with the special tools. 09940-14911: Steering stem nut wrench 09940-14960: Steering stem nut wrench socket Steering stem nut: 45 N·m (4.5 kgf-m, 32.5 lb-ft)
