CHASSIS 8-41 REMOVAL • Remove the cotter pin. (For E-03, 28, 33) • Loosen the axle nut 1. • Remove the under cowling. (8-5 to -6) • Raise the rear wheel off the ground and support the motorcy- cle with a jack or wooden block. • Remove the axle nut and draw out the rear axle. • Remove the rear wheel by disengaging the drive chain.  Do not operate the brake pedal with the rear wheel removed. • Remove the collar 2. E • Remove the brake disc 3. L P M A • Remove the collar 4. S • Loosen the rear sprocket mounting bolt and separate the rear sprocket 5 from its mounting drum 6. • Draw out the rear sprocket mounting drum 6 from the wheel hub. • Remove the rear sprocket mounting drum retainer 7.
