EXHAUST SYSTEM 6-9 • Make the No. 2 cable straight and turn in the cable adjuster 5 fully. • Loosen the lock-nuts 6 and turn the No.2 cable adjuster 7 in or out until the inner cable length C becomes 62 – 63 mm (2.44 – 2.48 in). • After adjusting the inner cable length C, tighten the lock-nuts 6. • Connect the No. 1 cable and No. 2 cable to the EXCVA pul- E ley. (6-6) L • Check the EXCVA to adjustment position. (6-4) P  Do not use the adjustable wrench to turn EXCVA pul- M ley so as not to cause damage to the internal gear of EXCVA. A • Install the pulley 8 to the shaft 9. S NOTE: Make sure that the shaft’s line D and cable slots E facing upward as shown. • Hold the EXCVA pulley with an adjustable wrench, and then tighten the pulley mounting bolt to the specified torque. EXCVA pulley mounting bolt: 5 N·m (0.5 kgf-m, 3.5 lb-ft)  When loosening or tightening the pulley bolt, be sure to fix the pulley with an adjustable wrench, or EXCVA may get damaged.
